Newton HydroBond 410 Geo Profile - 2m LengthNewton HydroBond 410 Geo Profile - 2m Length

Newton HydroBond 410 Geo Profile – 2m Length

Brand: Newton Waterproofing Systems
Product Code: A15
In Stock

Newton HydroBond 410 Geo Profile is compatible with HydroBond 410 GeoDrain, for preventing debris and back-fill from entering the cavity between the drainage core and the filter fabric.

£7.34 incl. VAT
£6.12 excl. VAT

Qty:

Newton HydroBond 410 Geo Profile is compatible with HydroBond 410 GeoDrain. Newton HydroBond 410 GeoProfile is applied to the top edge of the 410 GeoDrain membrane to prevent debris and back-fill from entering the cavity between the drainage core and the filter fabric.

Installed Performance Result Units Test Method
Thickness at 2kPa 11.3 mm EN ISO 9863-1
Water flow (in plane) 3.50 l/m2/s EN ISO 12958
Water flow through Geotextile 350 l/m2/s BS 6906-3
Compressive strength – Temporary loading 420 kPa EN ISO 25619-2
Water vapour diffusion resistance – Sd value >604 m BS EN 1931
Water vapour diffusion resistance – µ value >1208000 µ Calculated from SD value
Water vapour diffusion resistance >3020 MNs/g Calculated from SD value
Tensile strength (Machine direction) 15.4 kN/m2 EN ISO 10319
Tensile strength (Cross direction) 16.8 kN/m2 EN ISO 10319
Chemical resistance – Excellent 100 % EN14030
Oxidation resistance – Excellent 100 % EN ISO 13438
